48W系列ETL电源适配器
48W Switching Adapter
Electronic properties
Input Voltage············90VAC~264VAC
Input current············0.5A Max
Input Frequency···········47HZ~63HZ
Line regulation…
48W Switching Adapter
Electronic properties
Input Voltage············90VAC~264VAC
Input current············0.5A Max
Input Frequency···········47HZ~63HZ
Line regulation···········1% Max
Load regulation···········±5%
Temperature·············0~40℃
Storage temperature·········10℃~85℃
Relative Humidity··········10%~90%
Meet Efficiency Level ········Level VI
Output Characteristics:
Input Voltage OutputCurren Output Power5.0~15.0VDC 0.01A~5.0A 60.0W MAX
15.1~30.0VDC 0.01~3.97A 60.0W MAX
30.1~56.0VDC 0.01-1.99A 60.0W MAX
Safety
CB-------------IEC62368/IEC61558
ETL------------ETL62368/ ETL1310
GS/CE----------EN62368 /EN61558
PSE------------J62368/J61558
CCC----------GB4943
